FACTORY RACE 3.0 X 15.4 COIL-OVER INTERNAL BYPASS REMOTE SHOCK - DSC ADJUSTER

FOX devotes countless hours of research and development to design race-winning suspension that withstands incredible punishment and provides consistent performance you can rely on. Regardless of whether you are flying high over the desert or struggling to stick to a rock face on an off-camber climb, our shocks will give you the damping performance, suspension control and proper spring rate to get the job done.

• NEW proprietary Cerakote® protective ceramic coating over zinc plated basecoat
• 17-4 H900 hard chrome plated stainless steel shaft
• Owner serviceable and rebuildable
• JM92 MIL-SPEC oil developed specifically for off-road racing
• Black Anodized CNC Machined Aluminum Components

Attributes:

• Brand Name: FOX Offroad Shocks
• GTIN: 00692878900089
• Adjuster Type: DSC - Dual Speed Compression
• Body Diameter (in): 3.0
• Body Finish: FOX Grey Cerakote
• Body Material: Steel
• Bottom Mount: Eyelet
• Compressed Length (in): 29.60
• Extended Length (in): 44.99
• Eyelet Length (in): 5.50
• Fox Catalog: OFFROAD
• Label Name: 3.0 FRS, CO, CF IBP, P/B, HTO, DSC, Maverick R Rear, 15.4"
• Reservoir Dimensions: 2.25 x 10.00
• Reservoir Type: Piggyback
• Series: Factory Race
• Shaft Size (in): 7/8
• Top Mount: Eyelet
• Travel (in): 15.39
• Type: Coil-Over Internal Bypass
• Valving: 807-24-321

Extended Information:

• Country of Origin: US
• Emissions : 1

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 42.0000 x 11.0000 x 11.0000 inches
• Weight: 18.0000 POUNDS
