CLASS 1/2-1600 FRONT FACTORY RACE 2.0 X 10 EXTERNAL BYPASS (4 TUBE) REMOTE SHOCK (LEFT)

FOX devotes countless hours of research and development to design race-winning suspension that withstands incredible punishment and provides consistent performance you can rely on. Regardless of whether you are flying high over the desert or struggling to stick to a rock face on an off-camber climb, our shocks will give you the damping performance, suspension control and proper spring rate to get the job done.

• NEW proprietary Cerakote® protective ceramic coating over zinc plated basecoat
• 5/8" hard chrome plated 17-4 H900 stainless steel shaft
• Owner serviceable and rebuildable
• JM92 MIL-SPEC oil developed specifically for off-road racing
• Black Anodized CNC Machined Aluminum Components

Attributes:

• Brand Name: FOX Offroad Shocks
• GTIN: 00692878901253
• Adjuster Type: External Bypass Clicker - Gen 2
• Body Diameter (in): 2
• Body Finish: FOX Grey Cerakote
• Body Material: Steel
• Bottom Mount: Eyelet
• Bypass Tube Size: 1/2
• Bypass Tubes: 4
• Compressed Length (in): 17.13
• Extended Length (in): 27.19
• Eyelet Length (in): 1.68
• Fox Catalog: OFFROAD
• Hose: -10 x 31.00
• Label Name: CLASS 1/2-1600, FRONT, 2.0 FRS, (5/8" SHAFT), EXBP, 4T, R/R, 10", LEFT
• Mounting: 1/2 x 1-1/4
• Reservoir Dimensions: 2.17 x 8.00
• Reservoir Type: Remote
• Seal Kit: 803-04-023
• Series: Factory Race
• Shaft Size (in): 5/8
• Top Mount: Eyelet
• Travel (in): 10.06
• Travel (rounded): 10
• Type: External Bypass
• Valving: 807-24-070

Extended Information:

• Country of Origin: US
• Emissions : 1

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 35.0000 x 11.0000 x 6.0000 inches
• Weight: 0 POUNDS
